神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-004[00]) - BOOM GROUP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
317 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY02B00202F1 | [1] | | |
| 1. | 2444R1117D095 | [1] | HOSE,6.4mm ID x 950mm L | KOB |
| 2. | 2444R1117D098 | [1] | HOSE,6.40mm ID x 980mm L | KOB Superseded by part number: 2444R1117D100 |
| 3. | 2444R1117D190 | [1] | FLEXIBLE HOSE,6.40mm ID x 1900mm L | KOB |
| 4. | 2444R1117D200 | [1] | FLEXIBLE HOSE,6.40mm ID x 2000mm L | KOB |
| 5. | 2444R1117D235 | [1] | HOSE,6.40mm ID x 2350mm L | KOB Superseded by part number: HX21E04235DY |
| 6. | ZH32Z04002 | [2] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 7. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
