神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-014[00]) - HYDRAULIC LINES, BOOM CYLINDER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
235 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY42H00128F1 | [1] | Cylinder Boom | |
| 1. | YY42H00129F1 | [1] | Cylinder | |
| 2. | YY42H01488P1 | [1] | TUBE | KOB |
| 3. | ZX20H10074 | [2] | HOSE | KOB |
| 4. | ZX20H10078 | [2] | HOSE | KOB |
| 5. | YY42H01784P1 | [2] | BAND | KOB |
| 6. | YY42H01785P1 | [2] | BAND | KOB |
| 7. | 2432T2244 | [2] | CLAMP | KOB |
| 8. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB |
| 9. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 10. | ZD12A01600 | [1] | O-RING | KOB |
| 11. | ZD12P02600 | [1] | O-RING | KOB |
| 12. | ZM73C10045 | [2] | BOLT,M10x45mm - Course Thread | KOBSems |
| 13. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBCap |
| 14. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBCap |
| 15. | ZW26X10000 | [4] | LOCK WASHER | KOB |
| 16. | YY42H00130F1 | [1] | Cylinder | |
| 17. | YY42H01489P1 | [1] | TUBE | KOB |
| 18. | ZD12A01600 | [1] | O-RING | KOB |
| 19. | ZD12P02600 | [1] | O-RING | KOB |
| 20. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBCap |
| 21. | YY42H00131F1 | [1] | Cylinder | |
| 22. | YY42H01490P1 | [1] | TUBE | KOB |
| 23. | YY42H01491P1 | [1] | TUBE | KOB |
| 24. | ZD12A01600 | [2] | O-RING | KOB |
| 25. | ZD12P02600 | [2] | O-RING | KOB |
| 26. | ZS28C10030 | [8] | SCREW,Hex Socket Head, M10 x 30mm | KOBCap |
