神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-005[00]) - CRANKCASE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
425 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G0701013 | [1] | | |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONCrankcase Sub Assy. |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCrankcase |
| 4. | VA3430700501 | [4] | SLEEVE CYLINDER | KOB Superseded by part number: VA3430700502 |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONCap, Bearing |
| 6. | NSS | [3] | NOT SOLD SEPARAT | CONCap, Beearing |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONCap, Beearing |
| 8. | VA3430712701 | [1] | BUSHING | KOBCam No.1 |
| 9. | VA3430702802 | [1] | BUSHING | KOBCam No.2 |
| 10. | VA3430702901 | [1] | BUSHING | KOBCam No.3 |
| 11. | VA0482623500 | [10] | CAP | KOBSealing |
| 12. | VAME031865 | [10] | SCREW | KOBBearing Cap |
| 13. | VA0482621200 | [2] | CAP | KOBSealing |
| 14. | VA0482621800 | [7] | CAP | KOBSealing |
| 15. | VA32F0701100 | [2] | SEAL | KOBSide |
| 16. | VA32F0701200 | [4] | LUBE OIL NOZZLE | KOBLUBE OIL JET NOZZLE Assy. |
| 17. | VA3430702100 | [1] | PLUG | KOBCam Superseded by part number: VA3430702101 |
| 18. | VA3062050902 | [2] | PLUG | KOB |
| 19. | VA3432300502 | [1] | SHAFT | KOBIdler |
| 20. | VA3440714900 | [2] | PIN | KOBDowel |
| 21. | VAF284612000 | [2] | PIN | KOBDowel |
| 22. | VAF285004008 | [6] | PIN | KOBSpring |
| 23. | VA32F3600010 | [4] | CHECK VALVE | KOBAssy. |
| 24. | VAMF660034 | [8] | SEAL | KOB |
| 25. | VAMS661140 | [8] | PLUG | KOBTapered |
| 26. | VAF284606000 | [2] | PIN | KOBDowel |
| 27. | VA32G0705100 | [1] | PLUG | KOB |
| 28. | VA32F6102600 | [1] | O-RING | KOB |
