卡特零件查询（730） 153-8053: PUMP GP-WATER
广数供应链运营团队, 15 02月, 2025，浏览：
919 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 105-4213 | [1] | COVER-PUMP | |
| 2. | 105-4210 | [1] | GASKET | |
| 3. | 6V-3940M | [6] | BOLT(M8X1.25X25-MM) | |
| 4. | 9M-1974 | [6] | WASHER-HARD(8.8X16X2-MM THK) | |
| 5. | 7X-7731 | [1] | PLUG-PIPE(3/4-14-THD) | |
| 6. | 8T-6762 | [1] | PLUG-PIPE(1/2-14-THD) | |
| 7. | 147-5088 | [1] | SEAL AS-WATER PUMP | |
| 8. | 105-4212 | [1] | SHAFT-WATER PUMP | |
| 9. | 105-4209 | [1] | IMPELLER-PUMP | |
| 10. | 119-3025 | [1] | PLUG-FELT(WATER)(PUMP) | |
| | | | |
| | | | AVAILABLE GASKET KIT(S): |
| | 147-3781 | | KIT-GASKET(WATER PUMP) | |
| | | | (INCLUDES 0-RING SEALS & GASKETS) |
| | M | | METRIC PART |
