卡特零件查询（730） 352-2077: PUMP GP-WATER
广数供应链运营团队, 15 02月, 2025，浏览：
661 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 9Y-3513 | [1] | GEAR(41-TEETH) | |
| 2. | 105-4210 | [1] | GASKET | |
| 3. | 176-6995 | [1] | COVER-PUMP | |
| 4. | 176-6997 | [1] | SHAFT | |
| 5. | 176-6998 | [1] | IMPELLER-PUMP | |
| 6. | 176-6999 | [1] | HOUSING AS-PUMP | |
| 7. | 350-5417 | [1] | SEAL-WATER PUMP | |
| 8. | 1B-3867 | [2] | BALL BEARING | |
| 9. | 6V-3940M | [6] | BOLT(M8X1.25X25-MM) | |
| 10. | 6V-5842M | [1] | BOLT(M10X1.5X40-MM) | |
| 11. | 6V-9666 | [1] | WASHER-HARD(11X36X6-MM THK) | |
| 12. | 7X-7731 | [1] | PLUG-PIPE(3/4-14-THD) | |
| 13. | 8C-3100 | [1] | SEAL-LIP TYPE | |
| 14. | 8T-6762 | [1] | PLUG-PIPE(1/2-14-THD) | |
| 15. | 8T-9598 | [1] | RING-RETAINING | |
| 16. | 9M-1974 | [6] | WASHER-HARD(8.8X16X2-MM THK) | |
| | M | | METRIC PART |
