纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (04-007-00[01]) - LAMP, WORK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
657 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KHR2475 | [3] | WORK LAMP | SUM |
| 2. | KHR2476 | [1] | WORK LAMP | SUM Superseded by part number: KHR2475 |
| 3. | KHR2477 | [1] | BULB | SUM Superseded by part number: K340501 |
| 3.01. | KHN0539 | [2] | WASHER | SUM Superseded by part number: 14496621 |
| 4. | 159598A1 | [2] | PORTABLE LAMP | SUM |
| 5. | 152812A1 | [1] | BULB | SUM |
| 6. | 159615A1 | [1] | LIGHT | SUM Superseded by part number: 159598A1 |
| 7. | 896-11014 | [1] | WASHER,15.5mm ID x 28mm OD x 3mm Thk | CAS15,5 x 28 x 3 mm Superseded by part number: 87016615 |
| 8. | 892-16014 | [1] | LOCK WASHER,M14, Hvy | SUM |
| 9. | 167034A1 | [1] | NUT | SUM |
| 10. | 150834A1 | [2] | BRACKET | SUM |
| 11. | 627-16035 | [2] | BOLT,Hex, M16 x 2 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86529976 |
| 12. | 892-11016 | [2] | LOCK WASHER,16.4mm ID x 27.4mm OD x 5mm Thk | CAS Superseded by part number: 87016618 |
| 13. | 896-11016 | [2] | WASHER,17.5mm ID x 30mm OD x 4mm Thk | IH Superseded by part number: 86625266 |
