神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-026[00]) - COOLING SYSTEM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
299 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3424600011 | [1] | COVER ASSY | KOB |
| 2. | VA3431100400 | [1] | PIPE | KOBBy-Pass |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCover, Thermostat |
| 4. | VA32G4210200 | [1] | ELBOW | KOBWater Outlet |
| 5. | VA3424600700 | [1] | GASKET | KOB |
| 6. | VAMM316248 | [1] | PLUG | KOBDrain |
| 7. | VA0594601601 | [1] | WASHER, SEALING | KOBSEAL WASHER |
| 8. | VAMF241255 | [1] | BOLT | KOBW/Washer |
| 9. | VA3424600501 | [1] | FLEXIBLE HOSE | KOBRubber |
| 10. | VA32F4600100 | [1] | GASKET | KOB |
| 11. | VA3434611500 | [1] | SENSOR | KOBThermostat Superseded by part number: VA3434611501 |
| 12. | VA3634603500 | [1] | PACKING | KOB |
| 13. | VAMF241263 | [3] | BOLT | KOBW/Washer |
| 14. | VAF103508090 | [1] | BOLT | KOB |
| 15. | VAF251508000 | [3] | SPRING WASHER | KOB |
| 16. | VAF430002800 | [2] | HOSE CLAMP | KOB |
| 17. | VA32F4600300 | [1] | GASKET | KOBThermostat |
| 18. | VA0482660100 | [1] | WASHER | KOB |
| 19. | VAF103508025 | [2] | BOLT | KOB |
| 20. | VA3424610600 | [1] | SPACER | KOB |
