神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-036[00]) - INSTRUMENT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
183 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3439040200 | [1] | SWITCH | SMEngine Oil Pressure Superseded by part number: VA3439050200 |
| 2. | VA32G9000600 | [2] | SENSOR | KOBCrank & Cam Angle |
| 3. | VA32G9000700 | [1] | SENSOR | KOBBoost Pressure Superseded by part number: VA32G9010700 |
| 4. | VA32G9000200 | [1] | SENSOR | KOBWater Temp. Superseded by part number: VA32G9000201 |
| 5. | VA32G9000100 | [1] | SENSOR | KOBEngine RPM Superseded by part number: VA32G9000101 |
| 6. | VA32G8723100 | [1] | WIRE HARNESS | KOB Superseded by part number: VA32G8733100 |
| 7. | VAMF241225 | [1] | BOLT | KOBW/Washer |
| 8. | VAF115510020 | [3] | BOLT | KOB |
| 9. | VAF251510000 | [3] | SPRING WASHER | KOB |
| 10. | VA32G9004200 | [1] | | |
| 11. | VAMH020428 | [1] | CLIP | KOB |
| 12. | VAMH020433 | [1] | CLIP | KOB |
| 13. | VA0531800210 | [15] | BAND | KOBClip |
| 14. | VA0531741000 | [1] | | |
| 15. | VA32G9000400 | [1] | Corrugated | |
