凯斯零件查询(LB333R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (08.23[01]) - PICK UP SHIELDINGS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
733 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
395087
|
[2] |
INSULATOR BLOCK
|
ZED
|
| 2. |
87382333
|
[1] |
PLATE
|
ZED
|
| 3. |
87382331
|
[1] |
PLATE
|
ZED
|
| 4. |
87618194
|
[1] |
SHIELD
|
ZED
|
| 5. |
87617917
|
[1] |
SHIELD
|
ZED
, Serial Range: -C799
|
| 5. |
84203661
|
[1] |
SHIELD
|
ZED
, Start Serial: D800
|
| 6. |
84607783
|
[1] |
SHIELD
|
ZED
, Serial Range: -C799
|
| 6. |
84203655
|
[1] |
SHIELD
|
ZED
, Start Serial: D800
|
| 7. |
84607811
|
[1] |
SHIELD
|
ZED
, Serial Range: -C799
|
| 7. |
84203663
|
[1] |
SHIELD
|
ZED
, Start Serial: D800
|
| 8. |
87617896
|
[1] |
SHIELD
|
ZED
, Serial Range: -C799
|
| 8. |
84203656
|
[1] |
SHIELD
|
ZED
, Start Serial: D800
|
| 9. |
87617830
|
[1] |
SHIELD
|
ZED
|
| 10. |
392695
|
[2] |
SELF-TAP SCREW,Hex Wshr Hd, M6 x 16mm
|
GI
Superseded by part number: 80392695
|
| 11. |
9837759
|
[2] |
CLAMP,7mm ID, 10.5mm Bolt Hole, P Type
|
ZED
|
| 12. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 13. |
378245
|
[2] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 14. |
338263
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8
|
ZED
|
| 15. |
86511478
|
[15] |
BOLT,Hex Serr, M8 x 1.25 x 16mm
|
ZED
|
| 16. |
86508568
|
[8] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 17. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 18. |
9706755
|
[8] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 19. |
86505868
|
[2] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 20. |
84166460
|
[2] |
SUPPORT
|
ZED
, Start Serial: D722
|
| 21. |
86511479
|
[6] |
BOLT,Hex Flg, M8 x 20mm
|
WIN
, Start Serial: D722
|
| 22. |
9514605
|
[1] |
LOCK WASHER,9.8mm ID x 18.5mm OD x 1.5mm Thk
|
ZED
, Start Serial: D800
|
| 23. |
9514603
|
[4] |
LOCK,1/4 Turn, 28.8mm OAL
|
CUR
, Start Serial: D800
|
