神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-014[00]) - HYDRAULIC LINES, SWIVEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
283 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZA23F28016 | [4] | CONNECTION | KOB |
| 2. | ZA23F18008 | [2] | HYD CONNECTOR | KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied) |
| 3. | ZA23F15006 | [2] | HYD CONNECTOR | KOB |
| 4. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| 5. | ZH52X08000 | [1] | TEE,30 Degree Fl, Male, PF 1/2" x 1/2" x 1/2", O-Ring | KOB |
| 6. | ZE72X06000 | [2] | PLUG | KOB |
| 7. | ZD12P02900 | [4] | O-RING | KOB |
| 8. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 9. | ZD12P01400 | [2] | O-RING | KOB |
