纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-024-00[01]) - HYDRAULIC CIRCUIT - LOW FLOW - BOOM (7.25 M) - DIPPER (3.00 M) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
492 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 150496A1 | [1] | MOUNTING CLIP | SUM250 mm |
| 2. | KUV10780 | [1] | HYD. TUBE | SUM |
| 3. | KUV10790 | [1] | HYD. TUBE | SUM |
| 4. | KUV0373 | [1] | HYD. TUBE,21.6 mm ID x 27.2 mm OD | SUM |
| 5. | KMJ1976 | [2] | HOSE ASSY.,19.00 mm ID x 1510.00 mm | SUM |
| 6. | 163520A1 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1650.00 mm | SUM |
| 7. | KUV0374 | [2] | HYD. TUBE,20.8 mm ID x 27.2 mm OD | SUM |
| 8. | KUV0375 | [1] | HYD. TUBE,21.6 mm ID x 27.2 mm OD | SUM |
| 9. | KTV1433 | [2] | HYDRAULIC HOSE,19.00 mm ID x 1700.00 mm | SUM |
| 10. | KTV1432 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1700.00 mm | SUM |
| 11. | KTV1439 | [2] | HYD. TUBE,20.8 mm ID x 27.2 mm OD | SUM |
| 12. | 157580A1 | [1] | ELBOW,90º, 3/4" O-Ring x 3/4" | SUM |
| 13. | 154503A1 | [1] | O-RING | SUM |
| 14. | 167248A1 | [2] | FITTING | SUM |
| 15. | KHV10680 | [3] | VALVE SECTION | SUM |
| 16. | 152924A1 | [3] | PLUG | SUMG3/4 |
| 18. | 827-12070 | [6] | BOLT,Hex, M12 x 1.75 x 70mm, Cl 10.9 | CAS Superseded by part number: 86505259 |
| 19. | 150811A1 | [6] | WASHER | SUMW 12 Superseded by part number: 86625255 |
| 20. | 151486A1 | [9] | CLAMP BRACKET | SUM |
| 21. | 152085A1 | [7] | COLLAR | SUM |
| 22. | 167183A1 | [16] | BOLT,Sems, M12 x 60mm, Cl 10.9 | SUMM12 x 60 |
