神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-019[01]) - HYDRAULIC LINES, LOWER (PTPA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
349 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM19HU1002P1 | [2] | ELBOW | KOB |
| 2. | YM19HU1004P1 | [2] | HYD CONNECTOR | KOB |
| 3. | YY02HU1001D2 | [1] | HOSE | KOB |
| 4. | YY02HU1014D2 | [1] | HOSE | KOB |
| 5. | YY02HU1001D1 | [1] | HOSE | KOB |
| 6. | YY02HU1014D1 | [1] | HOSE | KOB |
| 7. | YM02HU1099P2 | [2] | GROMMET | KOB |
| 8. | YM02HU1101P1 | [2] | CLAMP | KOB |
| 9. | ZN18C12010 | [4] | NUT | KOB |
| 10. | ZW16H12000 | [4] | WASHER | KOB |
| 11. | YM02HU1100P1 | [2] | CLAMP | KOB |
