纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-031-00[01]) - HYDRAULIC CIRCUIT - HAND CONTROL PILOT (WITHOUT VALVE, PRESSURE RELIEF) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
534 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8. | KRJ4336 | [2] | HYDRAULIC HOSE,9.50 mm ID x 2200.00 mm | SUM |
| 9. | 168025A1 | [2] | HYDRAULIC HOSE,9.50 mm ID x 1950.00 mm | SUM |
| 12. | 162826A1 | [4] | ADAPTER | SUMG 3/8 |
| 22. | KHJ1345 | [2] | HYDRAULIC HOSE,9.52 mm ID x 2150.00 mm | SUM |
| 26. | 152747A1 | [2] | ADAPTER | SUM |
| 27. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 69. | KUJ10020 | [1] | VALVE SECTION | SUM Superseded by part number: KWJ11220 |
| 71. | 153526A1 | [1] | ELBOW | SUM |
| 72. | KHJ2234 | [1] | TEE | SUM |
| 75. | 162534A1 | [1] | HOSE | SUM |
| 76. | 162565A1 | [1] | HOSE ASSY. | SUM600 mm |
| 77. | 162835A1 | [1] | HOSE ASSY. | SUM600 mm |
| 78. | KRJ3569 | [1] | HOSE | SUM |
| 79. | KHJ1973 | [1] | VALVE | SUM Superseded by part number: KHJ17120 |
| 80. | 827-8045 | [2] | BOLT,Hex, M8 x 1.25 x 45mm, Cl 10.9 | CAS Superseded by part number: 16044131 |
| 81. | 153081A1 | [2] | WASHER | SUMW M8 |
| 82. | KHJ1291 | [1] | ORIFICE | SUM |
| 84. | KHJ1576 | [1] | BRACKET | SUM |
| 85. | 166052A1 | [2] | BOLT | SUMM10 x 25 Superseded by part number: 11106231 |
| 86. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 87. | 154475A1 | [1] | O-RING | SUM |
| 90. | 164107A1 | [1] | TEE,3/8" ORB x 3/8" - 19 NPT x 3/8" - 19 NPT | SUM |
| 93. | 159063A1 | [1] | HOSE | SUM3800 mm |
| 94. | 159062A1 | [1] | HOSE ASSY. | SUM3700 mm |
| 95. | KHJ10300 | [1] | HYDRAULIC HOSE | SUM3900 mm |
| 97. | KHJ12540 | [1] | HYDRAULIC HOSE | SUM3900 mm |
| 98. | 162531A1 | [1] | HOSE | SUM3600 mm |
| 106. | KHJ2773 | [1] | TEE | SUM |
| 110. | KHJ2847 | [1] | ADAPTER | SUM |
| 113. | KHJ0719 | [1] | ELBOW | SUM |
| 115. | KHJ10790 | [1] | FILTER SCREEN | SUM |
| 116. | 152127A1 | [1] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 119. | MPJ5480 | [1] | HOSE | SUM4200 mm |
| 120. | 159068A1 | [1] | HOSE | SUM4300 mm |
| 122. | KHJ12390 | [1] | HYDRAULIC HOSE | SUM4000 mm |
| 123. | KRJ4764 | [1] | HOSE | SUM |
| 124. | KHJ12550 | [1] | HYDRAULIC HOSE | SUM3700 mm |
| 125. | KRJ4970 | [1] | HOSE | SUM3800 mm |
| 126. | KHJ12560 | [1] | HYDRAULIC HOSE | SUM3900 mm |
