神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-023[00]) - LIFT CYLINDER (PTPA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
795 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YY01VU0001F1 | [1] | LIFT CYLINDER,Double Acting, 57.15mm Rod, 209.55mm Stroke | KOBAssembly, L.H. Lift, PTPA, Incl 1 - 18 |
| 1. | YY01VU0001S001 | [4] | RING | KOBWiper |
| 2. | YY01VU0001S002 | [1] | TUBE | KOBAssy. |
| 3. | YY01VU0001S005 | [1] | ROD | KOBAssy. |
| 4. | YY01VU0001S008 | [2] | BUSHING | KOB |
| 5. | YY01VU0001S011 | [3] | FITTING | KOBGrease Superseded by part number: YY01VU0005S011 |
| 6. | YY01VU0001S013 | [1] | LOCK NUT | KOB |
| 7. | YY01VU0001S012 | [1] | PISTON | KOB |
| 8. | YY01VU0001S014 | [1] | O-RING | SM |
| 9. | YY01VU0001S015 | [1] | BACK-UP RING | SM |
| 10. | YY01VU0001S016 | [1] | WIPER | SM |
| 11. | YY01VU0001S017 | [1] | O-RING | SM |
| 12. | YY01VU0001S004 | [1] | HEAD | KOB |
| 13. | YY01VU0001S018 | [1] | O-RING | SM |
| 14. | YY01VU0001S019 | [2] | WEAR RING | SM |
| 15. | YY01VU0001S020 | [1] | SEAL | SM |
| 16. | YY01VU0001S021 | [2] | WEAR RING | SM |
| 17. | YY01VU0001S022 | [1] | SEAL | SM |
| 18. | ZE72X08000 | [4] | PLUG | KOB |
| 19. | YY01VU0002F1 | [1] | CYLINDER | SMAssembly, R.H. Lift, Incl 1 - 18 |
