神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-055[02]) - SWIVEL JOINT INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
269 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2422J4745 | [1] | | |
| 2. | 2414T2712 | [1] | PIVOT | KOBPlate, Thrust |
| 3. | 2445Z917 | [11] | SEAL | KOBAssy. |
| 4. | ZD11G12500 | [1] | O-RING,3.1mm Thk x 124.4mm ID, 70 Duro | KOB |
| 5. | ZS23C08020 | [2] | SCREW,Hex Socket Head, M8 x 20mm | KOBCap |
| 6. | ZS23C08030 | [4] | SCREW,Hex Socket Head, M8 x 30mm | KOBCap Superseded by part number: ZS28C08030 |
| 7. | YY55V01001P1 | [1] | | |
| 8. | YY55V01002P1 | [1] | COVER | KOB |
| 9. | YN22T00194P1 | [1] | TYPE PLATE | KOB |
| 10. | 2420Z1036D3 | [2] | CLEVIS | KOB |
| 11. | YN55V01091P1 | [2] | PLUG | KOB |
| 12. | PV52D01007P1 | [5] | PLUG | KOB |
| 13. | ZD12P11000 | [2] | O-RING | KOB |
