神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-003[02]) - COUNTERWEIGHT INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
670 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YX60C00016F1 | [1] | | |
| 2. | PH05P01087D2 | [2] | RUBBER | KOB |
| 3. | YY60C01057P1 | [1] | RUBBER | KOB |
| 4. | YY60C01067P1 | [1] | RUBBER | KOB |
| 5. | YX60C01004P1 | [1] | INSULATION | KOB |
| 6. | YX60C01005P1 | [1] | INSULATION | KOB |
| 7. | YX60C01006P1 | [1] | INSULATION | KOB |
| 8. | YY60C01081P1 | [1] | FOAM INSULATION | KOB |
| 9. | YY60C01085D1 | [1] | RUBBER | KOB |
| 10. | YY60C01073P1 | [1] | FOAM INSULATION | KOB |
| 11. | YY60C01075P2 | [1] | INSULATION | KOB |
