神钢零件查询(ED160 BLADE) - HYDRAULIC EXCAVATOR - ASN LH02-01501 (9/12-12/13) (48.134.AA[02]) - IDLER, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
962 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN52D01006P1 | [1] | IDLER | KOB |
| 2. | 2405P482 | [2] | BUSHING | KOB |
| 3. | YN52D01011P1 | [2] | COLLAR | KOBCollar |
| 4. | 2445R442F1 | [2] | SEAL,110mm ID x 133.4mm OD x 33mm Thk | KOBFloating |
| 5. | YN52D01008P1 | [2] | PIN,16mm OD x 102mm L | KOB |
| 6. | YN52D01001P1 | [1] | SHAFT | KOB |
| 7. | ZD11G07000 | [2] | O-RING,69.40mm ID x 75.60mm OD x 3.10mm | KOB |
| 8. | PV52D01007P1 | [2] | PLUG | KOB |
| 9. | YN70V00006P1 | [1] | GREASE | KOBCylinder |
| 10. | YN54D01051P1 | [1] | YOKE | SMBracket |
| 11. | YN54D01038P1 | [1] | NUT | KOB |
| 12. | ZP26D08080 | [1] | PIN | KOBSpring |
| 13. | YN54D01043P2 | [1] | SPRING | KOB Superseded by part number: YN54D01044P1 |
| 14. | YN01V01099P1 | [1] | PISTON | KOB |
| 15. | YN54D01042P1 | [1] | COLLAR | KOB |
| 16. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOB |
| 17. | 2418U130D35 | [1] | PACKING | KOBU |
| 18. | LQ54D01023P1 | [2] | PIN | SM |
| 19. | YN54D01029P1 | [1] | COVER | KOB |
