| . . | 24100J20773F1 | [1] | REMOTE CONTROL ASSY (DOZER REWORK) (F1 ONLY) | |
| . . | 24100J20773F2 | [1] | REMOTE CONTROL ASSY (DOZER REWORK) (F2 ONLY) | |
| 1. | 2436U3059F2 | [1] | PILOT VALVE | KOB(SEE CPM) |
| 2. | 2436U1314F3 | [4] | SOLENOID VALVE | KOB(F1 ONLY) (SEE CPM) Superseded by part number: YA35V00009F1 |
| 3. | 2444Z2294 | [1] | HYD CONNECTOR | KOB1/4" PF x 41mm Long (Incls. (2) O-Rings ZD12P01100), (F1 ONLY) |
| 4. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), (F1 Only) |
| 5. | 2444T2580 | [2] | TEE | KOB3/8" PF x 61mm Long (No O-Ring supplied) |
| 6. | ZH42X04000 | [4] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004), (PF 1/4) |
| 8. | HX21E04035DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=350MM) Superseded by part number: 2420R349D035 |
| 9. | HX21E04060DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=600MM) Superseded by part number: 2420R349D060 |
| 10. | HX21E04075DX | [1] | HOSE | KOB(PF 1/4, L=750MM) (F1 ONLY) |
| 11. | 2444R1119D050 | [1] | HOSE | KOBPF 3/8, 500mm Long (19-11/16 in), (F1 ONLY) |
| 12. | HX21E04115DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=1150MM) (F1 ONLY) Superseded by part number: 2420R349D115 |
| 13. | HX21E04170DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=1700MM) |
| 14. | 2444R1119D100 | [1] | HOSE | KOB3/8" PF, 1000mm Long (39-3/8 in), (F1 ONLY) |
| 15. | HX21E04040DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=400MM) Superseded by part number: 2420R349D040 |
| 16. | HX21E04280DX | [1] | HOSE | KOB(PF 1/4, L=2800MM) |
| 17. | ZS13C06012 | [8] | SCREW | KOBM06x1.0x12mm, (F1 Only) |
| 18. | 2444T2580 | [1] | TEE | KOB3/8" PF x 61mm Long (No O-Ring supplied) |
| 19. | ZW22X06000 | [8] | ID 06 x OD 12.2 x Th 1.5mm, (F1 Only) | ID 06 x OD 12.2 x Th 1.5mm, (F1 Only) |
| 20. | 2444Z2544 | [3] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
| 21. | 2444Z3832 | [1] | TEE | HIT(PF 1/4 - 2X PF 3/8) |
| 22. | HX21E04210DX | [3] | FLEXIBLE HOSE | KOB(PF 1/4, L=2100MM) |
| 23. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 24. | 2444Z3783 | [4] | 90 ELBOW | KOB90° -- 1/4" PT (Incls. O-Ring ZD12P01100), (F1 ONLY) |
| 25. | HX21E04340DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=3400MM) |
| 26. | 2444R1119D200 | [1] | HOSE | KOBPF 3/8, 2000mm Long (78-3/4 in) |
| 27. | ZH32X04000 | [11] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), (F1 Only) |
| 29. | 2444Z3134 | [1] | TEE | KOB1/4" PF x 40mm Long |
| 30. | ZS13C08025 | [4] | SCREW | KOBM08x1.25x25mm Superseded by part number: ZS18C08025, 77276313 |
| 31. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm, (F1 Only) Superseded by part number: 83990583 |
| 35. | HH45X04004G2 | [1] | 45 ELBOW | HIT45° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 36. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 37. | 2444T3288 | [1] | 45 ELBOW | KOB45° -- (Incls. O-Ring ZD12P01100) |
| 38. | 2444Z2894 | [1] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 39. | 2444Z3756 | [1] | HYD CONNECTOR | KOB1/4" PT (Incls. 2 - O-Rings ZD12P01100) |
| 40. | 2444Z3785 | [1] | HYD CONNECTOR | KOB1/4" PT (Incls. O-Ring ZD12P01100) |
| 41. | 2444Z3903 | [1] | ELBOW | KOB90 DEGREE (PF 1/4) |
| 42. | 2479U1379 | [1] | PRESSURE SWITCH | HIT(Used for Swing, Travel, Auto Accel) Superseded by part number: 2479U1378 |
| 43. | 2416T27743 | [1] | BRACKET | KOB |
| 44. | 2416P19713 | [1] | (F1 ONLY) | (F1 ONLY) |
| 45. | HX21E04125DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=1250MM) |
| 46. | 2444Z2337 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100), (PF 1/4 - PF 3/8) |
| 47. | 2444Z2338 | [2] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| 48. | 2444T3298 | [1] | TEE | KOB3/8" PF - 1/4" PF (Incls. O-Ring ZD12P01100), (F1 ONLY) |
| 49. | 2444R1119D035 | [2] | FLEXIBLE HOSE | KOBPF 3/8, 350mm Long (13-49/64 in), (F1 Only) |
| 50. | 2416P19717 | [1] | BRACKET | KOB(F2 ONLY) |
| 51. | ZS13C10020 | [2] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 52. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 53. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 54. | HX21E04110DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=1100MM) (F1 ONLY) Superseded by part number: 2420R349D110 |
