现代零件查询R305LC-7 SWING REDUCTION GEAR(TYPE 2, #1535-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
411 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N . |
31N8-10200
|
[1] |
SWING MOTOR ASSY
|
|
| -1. |
31Q8-11141
|
[1] |
SWING REDUCTION GEAR
|
|
| 1. |
XKAQ-00451
|
[1] |
CASING
|
|
| 2. |
XKAQ-00760
|
[1] |
SHAFT-DRIVE
|
|
| 3. |
XKAQ-00146
|
[1] |
BEARING-ROLLER
|
|
| 4. |
XKAQ-00149
|
[1] |
SEAL-OIL
|
|
| 5. |
XKAQ-00027
|
[1] |
BEARING-ROLLER
|
|
| 6. |
XKAQ-00467
|
[1] |
CARRIER ASSY 2
|
|
| 7. |
XKAQ-00468
|
[1] |
CARRIER-2
|
|
| 8. |
XKAQ-00469
|
[4] |
GEAR-PLANET 2
|
|
| 9. |
XKAQ-00470
|
[4] |
PIN ASSY 2
|
|
| N10. |
XKAQ-00471
|
[1] |
PIN-2
|
|
| N11. |
XKAQ-00472
|
[1] |
BUSHING 2
|
|
| 12. |
XKAQ-00435
|
[8] |
WASHER-THRUST
|
|
| 13. |
XKAQ-00050
|
[4] |
PIN-SPRING
|
|
| 14. |
XKAQ-00473
|
[1] |
CARRIER ASSY 1
|
|
| 15. |
XKAQ-00453
|
[1] |
CARRIER-1
|
|
| 16. |
XKAQ-00454
|
[3] |
GEAR-PLANET 1
|
|
| 17. |
XKAQ-00440
|
[3] |
PIN ASSY-1
|
|
| N18. |
XKAQ-00441
|
[3] |
PIN-1
|
|
| N19. |
XKAQ-00079
|
[3] |
BUSHING-1
|
|
| 20. |
XKAQ-00417
|
[3] |
PLATE-SIDE 1
|
|
| 21. |
XKAQ-00416
|
[3] |
PLATE-SIDE 2
|
|
| 22. |
XKAQ-00041
|
[3] |
RING-STOP
|
|
| 23. |
XKAQ-00048
|
[3] |
PIN-SPRING
|
|
| 24. |
XKAQ-00455
|
[1] |
GEAR-SUN 2
|
|
| 25. |
XKAQ-00456
|
[1] |
GEAR-SUN 1
|
|
| 26. |
XKAQ-00457
|
[1] |
RING-GEAR
|
|
| 27. |
XKAQ-00466
|
[12] |
BOLT-SOCKET
|
|
| 28. |
XKAQ-00626
|
[1] |
COVER PLATE
|
|
| 29. |
XKAQ-00064
|
[8] |
BOLT-HEX
|
|
| 30. |
XKAQ-00627
|
[1] |
SPACER
|
|
| 31. |
XKAQ-00628
|
[1] |
RING-SPACER
|
|
| 32. |
XKAQ-00447
|
[1] |
PLATE-THRUST-3
|
|
| 33. |
XKAQ-00629
|
[1] |
GEAR-PINION
|
|
| 34. |
XKAQ-00761
|
[1] |
PLATE-LOCK
|
|
| 35. |
XKAQ-00756
|
[4] |
BOLT-HEX
|
|
| 36. |
XKAQ-00049
|
[1] |
PLUG
|
|
| 37. |
XKAQ-00066
|
[2] |
PLUG
|
|
| 38. |
XKAQ-00072
|
[2] |
PIN-KNOCK
|
|
| N39. |
XKAQ-00631
|
[4] |
BUSHING-2
|
|
| 40. |
XKAQ-00800
|
[1] |
AIR BREATHER ASSY
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
