纽荷兰零件查询(E135B) - CRAWLER EXCAVATOR TIER 3 - ASN YH05-07001 (N8TA13006) (1/08-) (09-10[00]) - FLYWHEEL HOUSING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
949 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G1200100 | [1] | HOUSING | KOBFlywheel |
| 2. | VA3431200080 | [1] | GASKET | KOB |
| 3. | VAF230010000 | [2] | NUT | KOB |
| 4. | VAMF407726 | [2] | STUD | KOB |
| 5. | VAF251510000 | [2] | SPRING WASHER | KOB |
| 6. | VAMF244855 | [8] | BOLT | KOB(Incls. Washer) |
| 7. | VAF200510025 | [2] | BOLT | KOB(Incls. Washer) |
| 8. | VAF200510030 | [10] | BOLT | KOB(Incls. Washer) |
| 9. | VA32G1200200 | [1] | BRACKET | KOBSensor |
| 10. | VA32F0704200 | [1] | GASKET | KOBRear |
| 11. | VAF103508025 | [1] | BOLT | KOB |
| 12. | VA32G1200300 | [4] | PIN | KOBDowel |
| 13. | VA0601613080 | [1] | O-RING | KOB |
| 14. | VA0553410000 | [1] | PLUG | KOB |
