| 1. | YM42HU1004P1 | [1] | TUBE,4211.4, 3129.8 mm L | KOBTube -- 4211.4mm Long (165-51/64 in) |
| 2. | YM42HU1005P1 | [1] | TUBE,4210.7, 3129.8 mm L | KOBTube -- 4210.7mm Long (165-25/32 in) |
| 3. | YM42HU1002P1 | [1] | TUBE | KOBTube -- 2384.3mm Long (93-7/8 in) |
| 4. | YM42HU1003P1 | [1] | TUBE | KOBTube -- 2386mm Long (93-15/16 in) |
| 5. | ZD12A01800 | [6] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 6. | ZM73C12035 | [14] | BOLT,M12x35mm - Course Thread | KOBM12x1.75x35mm (Incls. Washer) |
| 7. | YN42H02348P1 | [4] | CLAMP | KOB |
| 8. | YN42H02351P1 | [6] | CLAMP | KOB Superseded by part number: 84528894 |
| 9. | YN42H02349P1 | [2] | CLAMP | KOB |
| 10. | YN42H02319P1 | [6] | BUSHING,27.2mm ID x 34mm OD x 83mm L | SMID 27.20 x OD 34 x 83mm Long Superseded by part number: 84354627 |
| 11. | YN43H01524P1 | [2] | BUSHING,34mm ID x 53mm OD x 83mm L | KOBID 34 x OD 43 x 83mm Long |
| 12. | YN42H02355P1 | [4] | CLAMP | KOB Superseded by part number: 84528898 |
| 15. | PV02B01073D3 | [12] | CAP | KOB10.0mm Plastic Superseded by part number: YN64H01391D1 |
| 16. | YM42H01031P1 | [1] | TUBE,1474, 196 mm L | KOB1474mm Long (58-1/32 in) |
| 17. | YN42H01934D3 | [1] | HOSE | KOB1100mm Long (43-19/64 in) |
| 18. | ZX30U16110 | [1] | HOSE | KOB1100 mm Long (43-19/64 in) |
| 19. | YN43H01097P1 | [1] | CLAMP | KOB |
| 20. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4" PT - 1/4" PF |
| 21. | ZE13X16000 | [2] | FLANGE | KOB |
| 22. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB67°x1/8" PT |
| 23. | ZS28C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOBM10x1.50x35mm |
| 24. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOBM12x1.75x55mm |
| 25. | ZD12P02600 | [1] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 27. | ZW26K12000 | [5] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 28. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 29. | ZS28C12040 | [4] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
