纽荷兰零件查询(E175B) - CRAWLER EXCAVATOR TIER 3 (NA) - N7DA16301 - (5/07-) (07-01[03]) - NAME PLATE INSTALLATION, (EXTERIOR) LOCATION (YN22TU0023F4) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
769 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN20TU1040P2 | [1] | DECAL | KOBTag, Model and Serial Number |
| 2. | 4020Z64 | [12] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 4. | YN20T01866P2 | [1] | LABEL | KOBDecal, Lubrication Chart |
| 14. | YN20T01969P1 | [1] | DECAL | KOBDecal, No Step |
| 15. | YN20T01971P1 | [1] | Label, Maintenance | |
| 17. | YN20T01974P1 | [1] | DECAL | KOBDecal, Review manual |
| 18. | YN20T01975P1 | [1] | DECAL | KOBDecal, Falling objects and Lock |
| 26. | YN20T01979P1 | [2] | LABEL | KOBDecal, No a cup holder |
| 27. | YN20T01980P1 | [1] | DECAL | KOBDecal, Lock and Unlock |
| 28. | YN20T01981P1 | [1] | DECAL | KOBDecal, 12 Volt |
| 29. | YN20T01982P1 | [1] | DECAL | KOBTag |
| 30. | YN20T01983P1 | [1] | DECAL | KOBTag, Hot surface which could cause burns |
