神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (06-002[03]) - INSTRUMENT PANEL HARNESS ASSEMBLY 24100J20748F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
295 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J20748F3 | [1] | HARNESS ASSY, INST PANEL | |
| 2. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 3. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 4. | 2432R225D11 | [5] | CLIP | KOBClamp, Single -- ID 29 x 62.5mm Long Superseded by part number: ZC46X29011 |
| 5. | 2479U2109 | [1] | WIRE HARNESS | KOB |
| 9. | 2479U2169 | [1] | WIRE HARNESS | KOB |
