纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (3.006[00]) - LAMP MOUNTING - BOOM (YN80E00026F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
781 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | 2456R442F1 | [2] | LIGHT | KOB(NO COMPONENTS AT TIME OF PRINTING) |
| A2. | 2416T13056 | [2] | BRACKET | KOB |
| A3. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| A4. | 2418R323D11 | [2] | WASHER | KOBStar Lock -- ID 10 x OD 18 x Th 0.9mm |
| . . | YN15E00008F3 | [1] | HARNESS | KOBBoom Harness Assembly, YN15E00008F3, Incls. Refs. B1 & B2 |
| B1. | YN15E01034P1 | [1] | HARNESS | KOB |
| B2. | PY01P01043D7 | [1] | CABLE TIE,4.80mm W x 445mm L | KOBWire Ties -- 445mm Long |
