纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (5.009[00]) - CONTROL LINES, PUMP (YN06H00077F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
551 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZX22M12048 | [1] | HOSE | KOB480mm Long (18-57/64 in) |
| 2. | 2420R537D052 | [1] | HOSE,9.60mm ID x 520mm L | KOB Superseded by part number: 2420R537D055 |
| 3. | 2420R537D050 | [1] | HOSE,9.53mm ID x 500mm L | KOB |
| 4. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| 5. | YN50V00020F1 | [1] | HYDRAULIC OIL FILTER | SMFilter, Inline |
| 6. | YN06H01044P1 | [1] | TEE | KOB(2) 1/4" PF x (2) 3/8" PF x 61mm Long (Incls. O-Rings ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of YN06H01044P1), ID 10.80 ± 0.18 x OD 15mm, Not Shown |
| 7. | HH25R04004G5 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 8. | ZH22X12000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| . . | ZD12P02400 | [1] | O-RING | KOB(Part of ZH22X12000), ID 23.70 ± 0.24 x OD 30mm, Not Shown |
| 9. | ZH22X06000 | [3] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of ZH22X06000), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| 10. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- (Incls. O-Ring 237-6012) |
| . . | 237-6012 | [1] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | CAS(Part of ZH32X12000), SAE No. 12-1, Not Shown Superseded by part number: 72186120, 167266, 79051113 |
| 11. | 2444Z2345 | [6] | ELBOW | KOB90° -- (Incls. O-Rings ZD12P01400 & ZD12P01800) |
| . . | ZD12P01800 | [1] | O-RING | KOB(Part of 2444Z2345), ID 17.80 ± 0.21 x OD 22mm, Not Shown |
| 12. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° -- 1/4"PF (Incls. O-Ring ZD12P01100) |
