纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (5.037[00]) - HARNESS ASSEMBLY, UPPER (NIBBLER & BREAKER W/ROTATION + HAND) (LC13E00051F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
543 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LC13E01291P1 | [1] | WIRE HARNESS | KOB |
| 2. | PY01P01043D3 | [23] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 3. | YN24S00010P1 | [4] | RELAY | KOB |
| 4. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 5. | LC13E01289P1 | [1] | WIRE HARNESS | KOB |
| 6. | LC13E01295P1 | [1] | HARNESS | KOBHARNESS |
