纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (5.039[00]) - SUN VISOR ASSEMBLY (YN55C00013F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
402 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN02C03645P1 | [1] | BRACKET | SMAssembly |
| 2. | YN55C01021F1 | [1] | GUARD | SMCover |
| 3. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| 4. | ZM73C10030 | [2] | BOLT,M10x30mm - Course Thread | KOBM10x1.50x30mm (Incls. Washer) |
| 5. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 6. | ZW16P08000 | [8] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 7. | PH21C01136DL | [1] | GASKET,1380mm L | SMWeatherstrip -- 1680mm Long (66-9/64 in) |
| 8. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
