纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (5.042[00]) - COUNTERWEIGHT INSTALLATION (EXTREME/LONG REACH) (YN60C00201F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
597 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN60C01300P1 | [4] | CAP,M3 x 8mm | KOBScrew -- M27x335mm |
| A2. | HY26Y28060G3 | [4] | WASHER | KOBID 27.5 x OD 60 x Th 12mm |
| A3. | YN60C01470P1 | [3] | SHIM | KOBShim (1.6) |
| A4. | YN60C01471P1 | [3] | SHIM | KOBShim (2.3) |
| A5. | YN60C01472P1 | [4] | SHIM | KOBShim (3.2) |
| B1. | LQ60C01207P2 | [1] | FOAM INSULATION | KOB |
| B3. | YN60C01430P1 | [1] | FOAM INSULATION | KOBInsulation |
| B4. | LC21C01730P1 | [2] | PANEL | KOB |
| B5. | ZM73C12030 | [6] | BOLT,M12x30mm - Course Thread | KOBM12x1.75x30mm (Incls. Washer) |
| C1. | YN60C00258P1 | [1] | COUNTERWEIGHT,5.81 Metric Tons | KOBCounterweight -- Replaces YN60C00203P1 |
| C2. | NSS | [2] | NOT SERVICED SEPARATELY | CONFiller |
