纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (5.044[00]) - LAMP INSTALLATION (YN80E00071F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
720 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM80S00001F1 | [1] | LAMP | KOBFlashing, F1 -- Left Hand |
| 2. | YM80S00001F2 | [1] | LAMP | KOBFlashing, F2 -- Right Hand |
| 3. | 2420R372D19 | [1] | GROMMET | KOB |
| 4. | 2420Z1322 | [1] | GROMMET | KOB |
| 5. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 6. | YN13E01375P1 | [3] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
