神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (07-008) - SLEWING RING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
686 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N8102F1 | [1] | SLEWING RING | KOBRING, SLEWING Superseded by part number: YM40FU0002F1 |
| 1. | 2425N452F1 | [1] | | |
| 1-B. | 2420T4508 | [1] | PLUG | KOB |
| 1-C. | 2419T1964D1 | [1] | PIN | KOBTaper -- OD 10 x 70mm Long |
| 2. | 2425N453 | [1] | | |
| 3. | 2425T380 | [87] | BALL | KOB |
| 4. | 2425T381 | [87] | RETAINER | KOB |
| 5. | 2445P165D10 | [1] | SEAL | KOB(L=3188mm) Superseded by part number: YN40F01024D4 |
| 6. | 2445P165D9 | [1] | SEAL | KOB(L=3177mm) Superseded by part number: YN40F01024D4 |
| 7. | YN22T00191P1 | [1] | PLATE | KOBNAME |
| 8. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 9. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
