神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (07-011[02]) - DOZER INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
431 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J20890F1 | [1] | DOZER INSTAL | |
| 1. | 24100J20768F1 | [1] | BLADE ASSY DOZER | BLADE ASSY DOZER |
| 2. | 2444R3142 | [4] | HOSE | KOB |
| 3. | 2444R3143 | [2] | HOSE | |
| 4. | 2444R3149 | [4] | HOSE | KOB |
| 5. | ZE72X08000 | [4] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800) |
| 8. | ZA33F15008 | [4] | ELBOW | KOB |
| 9. | 2414P10941 | [1] | GUARD | KOB |
| 10. | 2414P10942 | [1] | GUARD | KOB |
| 11. | ZS18C10020 | [11] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 12. | ZW26X10000 | [11] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
