纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (7.015[02]) - NAME PLATE INSTALLATION, (LIFT CHARTS) (YN22TU0022F1 - F8), FIGURE 2 OF 3 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
748 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN20TU1233P2 | [1] | LABEL | KOBLabel 600mm |
| 2. | YN20TU1234P2 | [1] | LABEL | KOBLabel 600mm |
| 3. | YN20TU1235P2 | [1] | LABEL | KOBLabel 700mm |
| 4. | YN20TU1236P2 | [1] | LABEL | KOBLabel 700mm |
| 5. | YN20TU1237P2 | [1] | LABEL | KOB800mm |
| 6. | YN20TU1238P2 | [1] | LABEL | KOB800mm |
| 7. | YN20TU1239P2 | [1] | LABEL | KOBLabel 900mm |
| 8. | YN20TU1240P2 | [1] | LABEL | KOBLabel 900mm |
