神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (07-012) - DOZER BLADE ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
819 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J20768F1 | [1] | DOZER | DOZER |
| 1. | 24100J21252F1 | [1] | GLOW PLUG | GLOW PLUG |
| 2. | 24100J21251F1 | [1] | DOZER BLADE | KOBBLADE ASSY Superseded by part number: AW206-004-017 |
| 3. | AW208-504-008 | [1] | LINK | KOB |
| 4. | AW545-059-026 | [2] | BOLT | KOB |
| 5. | AW317-002-558 | [1] | CYLINDER | KOB |
| 6. | AW717-175-078 | [6] | PIN | KOB |
| 7. | AW317-002-559 | [2] | CYLINDER | KOB |
| 8. | AW545-059-032 | [6] | BOLT | KOB |
| 9. | AW545-023-004 | [6] | NUT | KOB |
| 10. | 24100J21253F1 | [1] | KIT, HYD PIPING | |
| 11. | AW545-059-054 | [2] | BOLT | KOB |
| 12. | AW545-059-053 | [4] | BOLT | KOB |
| 13. | AW717-175-094 | [4] | PIN | KOB |
| 14. | AW717-175-093 | [2] | PIN | KOB |
| 15. | 2420T9270 | [14] | SHIM | KOBSHIM Superseded by part number: AW545-069-068 |
| 16. | AW717-970-092 | [2] | RETAINER | KOBPLATE, WASHER |
| 17. | AW317-002-557 | [2] | LIFT CYLINDER | KOBLIFT |
| 18. | AW545-023-003 | [6] | NUT | KOB |
| 19. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 20. | AW545-069-054 | [12] | SPACER | KOB |
