神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (09-004) - REWORK, CONTROL SYSTEM (AUTO WARM-UP) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
788 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J19395F2 | [1] | CONTROL | KOBREWORK, SYSTEM |
| 1. | 2436U1314F3 | [1] | SOLENOID VALVE | KOB Superseded by part number: YA35V00009F1 |
| 2. | 2416T27743 | [1] | BRACKET | KOB |
| 3. | YN24S00001P1 | [1] | RELAY,24V, 10 Amp | KOB(R-13) |
| 4. | 2479U1290 | [1] | RELAY | KOB(R-12) |
| 5. | 2479U1224F6 | [1] | SWITCH | KOB |
| 6. | 2456R445D2 | [1] | LAMP | KOB |
| 7. | ZM66C06016 | [1] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 8. | ZM66C06020 | [2] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| 9. | ZS13C06016 | [2] | SCREW | KOBM06x1.0x16mm |
| 10. | ZS13C10020 | [2] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 11. | ZW22X06000 | [2] | ID 06 x OD 12.2 x Th 1.5mm | ID 06 x OD 12.2 x Th 1.5mm |
| 12. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 13. | ZH32X04000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 15. | 2444T2524 | [1] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 17. | 2444Z2336 | [1] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 18. | 2444Z3465 | [1] | TEE | KOBPF 1/4 - PF 3/8, (Incls. O-Ring ZD12P01100) |
| 19. | 2444Z3834 | [1] | TEE | KOB(PF 1/4 - PF 3/8) |
| 22. | HX21E04050DX | [2] | HOSE | KOB |
| 23. | HX21E04200DX | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2420R349D200 |
| 24. | 2444R1120D040 | [1] | HOSE | KOB400mm Long (15-3/4 in) |
| 25. | 2479U2058 | [1] | PRESSURE SWITCH | KOB |
| 26. | 2444R3061 | [1] | TEE | KOB(PF 1/8 - PT 1/8) |
| 27. | 2436R818F2 | [2] | VALVE PRESSURE RELIE | KOB |
| . . | NSS | [1] | NOT SOLD SEPARAT | CONITEMS TO BE REMOVED |
| 901. | 2444Z2338 | [-1] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| 902. | 2444Z2337 | [-1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 903. | 2444Z3322D3 | [-1] | HYD CONNECTOR | KOB1/8"PF x 1/8"PT x 25mm Long (Incls. O-Ring) |
