纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.008[00]) - VALVE ASSEMBLY, CONTROL (YN30V00104F1) (HC100) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
413 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN30V00104F1 | [1] | HYDRAULIC VALVE | SMAssembly, Control |
| 101. | NA | [1] | NOT SERVICED | FORCase |
| 161. | ZD12G05500 | [1] | O-RING,3.1mm Thk x 54.4mm ID, 90 Duro | KOBID 54.40 ± 0.49 x OD 60mm |
| 162. | ZD12P00900 | [1] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 201. | YN30V00104S201 | [1] | COVER | SM |
| 301. | YN30V00104S301 | [1] | SPOOL | SMSpool |
| 321. | YN30V00104S321 | [1] | SPRING | SM |
| 601. | YN35V00050F1 | [1] | SOLENOID VALVE,Cartridge W/Coil | KOBAssembly, Solenoid -- See Figure 8.008.01 |
| 701. | ZS23C10025 | [2] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm Superseded by part number: ZS28C10025 |
| 702. | YX35V00002S171 | [2] | SCREW,Hex Socket Head, M5 x 12mm | KOBM05x0.8x12mm Superseded by part number: ZS23C05012 |
| 703. | ZS23C12105 | [3] | SCREW,Hex Socket Head, M12 x 105mm | KOBM12x1.75x105mm |
| 704. | ZS23C12080 | [1] | SCREW,Hex Socket Head, M12 x 80mm | KOBM12x1.75x80mm |
