凯斯零件查询(LB334S) - BALER (9/12-) (27.500.060) - TANDEM AXLE, HYDRAULIC BRAKES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
601 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84531518
|
[1] |
AXLE
|
ZED
|
| 1. |
84521821
|
[1] |
AXLE
|
ZED
|
| 1. |
84563815
|
[1] |
AXLE
|
ZED
|
| 1. |
47926447
|
[1] |
AXLE
|
ZED
, Start Serial: D146
|
| 1. |
47926442
|
[1] |
AXLE
|
ZED
, Start Serial: D146
|
| 2. |
84521848
|
[2] |
BRAKE
|
ZED
Incl 3 - 7, 22
|
| 3. |
84014235
|
[2] |
SLEEVE
|
ZED
|
| 4. |
84220999
|
[2] |
LOCK WASHER
|
ZED
|
| 5. |
100024
|
[2] |
NUT,M24 x 1.5, Cl 8
|
MKT
|
| 6. |
84519730
|
[2] |
O-RING,2.62mm Thk x 37.77mm ID
|
ZED
|
| 7. |
84519464
|
[2] |
HOOD
|
ZED
|
| 8. |
84563584
|
[16] |
STUD
|
ZED
, Serial Range: -C084
|
| 8. |
47456247
|
[16] |
STUD
|
ZED
, Start Serial: D085
|
| 9. |
84521826
|
[2] |
BRAKE DRUM
|
ZED
|
| 10. |
84521823
|
[2] |
OIL SEAL
|
ZED
|
| 11. |
84100482
|
[2] |
RING
|
ZED
|
| 12. |
84521825
|
[2] |
HUB
|
ZED
|
| 13. |
84100484
|
[2] |
RING
|
ZED
|
| 14. |
140069
|
[2] |
WASHER,M15 x 24 x 2 Thk
|
ZED
|
| 15. |
84212727
|
[2] |
COTTER PIN
|
ZED
|
| 16. |
84521828
|
[2] |
NUT
|
ZED
Superseded by part number: 84100486
|
| 17. |
14301931
|
[12] |
HEX SOC SCREW,M8 x 1.25 x 10mm, Cl 10.9, Full Thd
|
LEC
|
| 18. |
84521831
|
[2] |
COVER
|
ZED
|
| 19. |
84100485
|
[2] |
BALL BEARING,60mm ID x 110mm OD x 29.75mm W
|
ZED
Superseded by part number: 87622924
|
| 20. |
84100483
|
[2] |
BALL BEARING,75mm ID x 130mm OD x 33.25mm W
|
ZED
Superseded by part number: 26800210
|
| 21. |
84528423
|
[2] |
CAMSHAFT
|
ZED
|
| 21. |
84521838
|
[2] |
CAMSHAFT
|
ZED
|
| 21. |
47923279
|
[2] |
CAMSHAFT
|
ZED
, Start Serial: D146
|
| 22. |
300632
|
[2] |
SNAP RING,M38, External
|
ZED
Superseded by part number: 11068676
|
| 23. |
84301463
|
[2] |
LEVER
|
PLO
|
| 24. |
84045556
|
[2] |
CIRCLIP
|
ZED
|
| 25. |
84800533
|
[2] |
PIN
|
PLO
Superseded by part number: 84014240
|
| 26. |
84800532
|
[2] |
SPRING
|
PLO
|
| 27. |
84014242
|
[2] |
CYLINDER
|
ZED
|
| 28. |
84800534
|
[2] |
PIN
|
PLO
|
| 29. |
10797401
|
[2] |
COTTER PIN,M5 x 36
|
TTF
|
| 30. |
150024
|
[2] |
LUBE NIPPLE,45 Degree, M8 x 1
|
NH
|
| 31. |
84563749
|
[1] |
FRONT AXLE
|
ZED
Incl 1 - 30, 32 - 35
|
| 31. |
84521750
|
[1] |
FRONT AXLE
|
ZED
Incl 1 - 30, 32 - 35
|
| 31. |
84563806
|
[1] |
REAR AXLE
|
ZED
Incl 1 - 30, 32 - 35
|
| 31. |
84564068
|
[1] |
REAR AXLE
|
ZED
Incl 1 - 30, 32 - 35
|
| 31. |
84531512
|
[1] |
FRONT AXLE
|
ZED
Incl 1 - 30, 32 - 35, Serial Range: -C145
|
| 31. |
47926343
|
[1] |
FRONT AXLE
|
ZED
Incl 1 - 30, 32 - 35, Start Serial: D146
|
| 31. |
84526186
|
[1] |
FRONT AXLE
|
ZED
Incl 1 - 30, 32 - 35, Serial Range: -C145
|
| 31. |
47926361
|
[1] |
FRONT AXLE
|
ZED
Incl 1 - 30, 32 - 35, Start Serial: D146
|
| 32. |
84521844
|
[1] |
CROWN NUT
|
ZED
Incl 15, 16
|
| 33. |
84521845
|
[1] |
KIT
|
ZED
Incl 17, 18
|
| 34. |
47462799
|
[2] |
FIP KIT
|
ZED
Incl 8
|
| 35. |
84521846
|
[1] |
SEAL KIT
|
ZED
Incl 10, 11, 13
|
