凯斯零件查询(LB334S) - BALER (9/12-) (31.201.020) - POWER TAKE-OFF, HITCH FRAME Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
431 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84259832
|
[1] |
SUPPORT
|
ZED
|
| 2. |
87758780
|
[1] |
BEARING ASSY,45 mm ID x 85 mm OD x 52 mm
|
ZED
Incl 11 - 13, Serial Range: -C136 Superseded by part number: 87717099
|
| 2. |
47938764
|
[1] |
BALL BEARING
|
ZED
Incl 11 - 13, Start Serial: D137
|
| 3. |
87716646
|
[1] |
SHIELD
|
ZED
|
| 4. |
573305
|
[1] |
CLAMP,5.56" - 6.5"
|
GI
|
| 5. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 6. |
140046
|
[7] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 7. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 8. |
9706687
|
[3] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 9. |
362776
|
[4] |
WASHER
|
ZED
|
| 10. |
86508568
|
[4] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 11. |
87744011
|
[1] |
BEARING HOUSING,45 mm ID x 85 mm OD x 52 mm
|
ZED
, Serial Range: -C136
|
| 11. |
47818799
|
[1] |
BEARING HOUSING
|
ZED
, Start Serial: D137 Superseded by part number: 47358268
|
| 12. |
9839347
|
[1] |
BEARING ASSY,45mm ID x 85mm OD x 22mm W
|
ZED
, Serial Range: -C136
|
| 12. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Bearing Incl in 2, Start Serial: D137
|
| 13. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 14. |
84388820
|
[1] |
SLEEVE,45mm ID x 60mm OD x 22.8mm L
|
ZED
, Serial Range: -C136
|
| 15. |
86566989
|
[1] |
CABLE TIE,208mm L
|
ZED
, Serial Range: -C136
|
| 16. |
47534604
|
[1] |
RING
|
ZED
, Start Serial: D137
|
| 17. |
5135061
|
[1] |
CIRCLIP,M45, Ext
|
TTF
, Start Serial: D137
|
