神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-044) - PILOT MANIFOLD ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
388 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN20VU0001F1 | [1] | INLET MANIFOLD | KOB |
| 2. | YN20VU0001S002 | [1] | FILTER | KOB |
| 2-1. | 24100P5113 | [1] | O-RING | KOBSEAL (FILTER) Superseded by part number: 2445Z1592, 2445Z1591 |
| 2-1A. | 2445Z1591 | [1] | O-RING | KOB |
| 2-1B. | 2445Z1592 | [1] | O-RING | KOB |
| 3. | YN20VU0001S003 | [2] | CHECK VALVE | KOB |
| 3-1. | 24100P5114 | [4] | REPAIR KIT | KOBSEAL (CV & RV) Superseded by part number: 2445Z1593, 2445Z1595, 2445Z1594 |
| 3-1A. | 2445Z1594 | [1] | SEAL | KOB(BACK-UP) |
| 3-1B. | 2445Z1593 | [1] | O-RING | KOB |
| 3-1C. | 2445Z1595 | [1] | O-RING | KOB |
| 4. | YN20VU0001S004 | [1] | CHECK VALVE | KOB |
| 5. | YN20VU0001S005 | [1] | VALVE PRESSURE RELIE | KOB |
| 6. | YN20VU0001S007 | [2] | PLUG | KOBHEX |
| 6-1. | 2445Z1596 | [1] | O-RING | KOB |
