纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.027[00]) - VALVE ASSEMBLY, SOLENOID (YN35V00047F1) (HC850) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
235 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN35V00047F1 | [1] | HYDRAULIC VALVE | SMAssembly, Solenoid Superseded by part number: YN35V00047F3 |
| 101. | YN35V00047S101 | [1] | CASE | KOB |
| 171. | YX35V00002S171 | [16] | SCREW,Hex Socket Head, M5 x 12mm | KOB Superseded by part number: ZS23C05012 |
| 601. | YN35V00048F1 | [3] | SOLENOID VALVE | KOBAssembly, Solenoid -- See Figure 8.028 (HC851) |
| 602. | YN35V00049F1 | [1] | SOLENOID VALVE | KOBAssembly, Solenoid -- See Figure 8.029 (HC852) |
| 701. | YN35V00050F1 | [3] | SOLENOID VALVE,Cartridge W/Coil | KOBAssembly, Solenoid -- See Figure 8.030 (HC853) |
| 702. | YN35V00051F1 | [1] | SOLENOID VALVE | KOBAssembly, Solenoid -- See Figure 8.031 (HC854) |
| 901. | YY35V00007S901 | [1] | Name Plate | |
