神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-019) - VALVE ASSY, SOLENOID, (2436R884F1, 2436R884F2 & 2436R884F3) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
223 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R884F1 | [1] | VALVE | KOB Superseded by part number: 2436R884F3 |
| . . | 2436R884F2 | [1] | SOLENOID VALVE | SOLENOID VALVE |
| . . | 2436R884F3 | [1] | VALVE | KOB |
| 311. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 312. | NSS | [1] | NOT SOLD SEPARAT | CONSLEEVE |
| 324. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 363. | 2436R884S363 | [1] | O-RING | KOB Superseded by part number: YN35V00004S362 |
| 364. | 2436R884S364 | [1] | O-RING | KOB Superseded by part number: YN35V00004S363 |
| 801. | 2436R884S801 | [1] | VALVE | KOBF1 & F3 ONLY Superseded by part number: 2436R884F3 |
| 805. | 2436R884S805 | [1] | O-RING | KOB |
| 901. | 2436R884S901 | [1] | SOLENOID VALVE | KOBF2 ONLY Superseded by part number: 2436R884F4 |
