纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.038.01[00]) - VALVE ASSEMBLY, RELIEF (YN22V00037F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
734 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN22V00037F1 | [1] | HYDRAULIC VALVE | SMAssembly, Relief |
| 1. | NA | [1] | NOT SERVICED | FORPlug |
| 7. | ZD12P00800 | [1] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 07.80 ± 0.16 x OD 11mm |
| 8. | ZD12P01600 | [1] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 9. | YN22V00037S561 | [1] | O-RING | SM |
| 10. | YN22V00037S562 | [1] | RING | SMBack-Up |
