| . . | YN15V00037F1 | [1] | HYDRAULIC MOTOR | SMPropelling -- Used from date 03/31/2006 - 02/22/2008, Figure 2 of 2 Superseded by part number: YN15V00037F2 |
| . . | YN15V00037F2R | [1] | REMAN-HYD MOTOR | KOBE215B TIER 3 (1/07-), Reman For New P/N YN15V00037F1 |
| . . | YN15V00037F2C | [1] | CORE-MOTOR HYDRAULIC | KOBReturn Number |
| 200. | YN22V00036F1 | [1] | VALVE | KOBAssembly, Relief -- Incls. Refs. 201-210 |
| 201. | NSS | [2] | NOT SERVICED SEPARATELY | CONSeat, Valve |
| 210. | 2436U562S8 | [2] | O-RING | HITO-Ring |
| 301. | YN15V00037S301 | [1] | FLANGE | KOB |
| 324. | YN15V00037S324 | [2] | PLUG | KOB |
| 325. | YN15V00037S325 | [2] | SEAT | KOBSpring |
| 329. | YN15V00037S329 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB Superseded by part number: ZD12P03400 |
| 330. | YN15V00037S330 | [2] | SPRING | KOB |
| 343. | ZS23C16040 | [8] | CAPSCREW,Hex Socket Head, M16 x 40mm | KOBSCREW M16x2.0x40mm |
| 345. | 2436U1427S25 | [15] | PLUG | KOB |
| 363. | YN15V00037S363 | [1] | SPOOL | KOB |
| 364. | 2436R874S3 | [1] | FLEXIBLE JOINT | KOBConnector |
| 365. | 2436R874S6 | [1] | PIN | KOB |
| 366. | 2436R874S7 | [1] | SPRING | KOB |
| 367. | 2436R874S5 | [1] | SPRING SEAT | KOB |
| 370. | LC15V00023S062 | [1] | PLUG | KOB |
| 371. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 372. | LC15V00023S067 | [2] | RESTRICTOR | KOB |
| 373. | LC15V00023S068 | [2] | SPRING | KOB |
| 374. | YN15V00017S038 | [5] | PLUG | KOB |
| 375. | ZD12P00800 | [6] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 07.80 ± 0.16 x OD 11mm |
| 376. | GN15V00010S024 | [3] | RESTRICTOR | KOBReplaces YN15V00037S376 |
| K. | YN15V00037R400 | [1] | PISTON | KOBKit, Repair -- Contains Items 105 & 106 |
| K. | YN15V00037R410 | [1] | PISTON | KOBKit, Repair -- Contains Items 161 & 163 |
| K. | YN15V00037R420 | [1] | PLATE | KOBKit, Repair -- Contains Items 103 & 167 |
| K. | YN15V00037R430 | [1] | VALVE | KOBKit, Repair -- Contains Items 301, 323, 341, 343, 345 & 363-380 |
| K. | YN15V00037R440 | [1] | VALVE | KOBKit, Repair -- Contains Items 323, 326-328 & 331 |
| K. | YN15V00037R450 | [1] | SEAL KIT | KOBContains Items 31, 132, 135, 139, 329, 369, 371, 375, 379 & 380 |
