神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (04-003[01]) - SWING PRIORITY KIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
225 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N10181F1 | [1] | SWING PRIORITY KIT | |
| 1. | 2436U1310F1 | [1] | VALVE | KOBASSY (SEE CPM) |
| 2. | 2436R1062D61 | [2] | CHECK VALVE | KOB |
| 3. | 2436U2675F2 | [1] | CONTROL VALVE | KOB(SEE CPM) |
| 4. | 2436U1314F1 | [1] | VALVE | KOBASSY, SOL (SEE CPM) |
| 5. | 2479U1190F11 | [1] | SWITCH | KOB |
| 6. | 2444Z2451 | [2] | HYD CONNECTOR | KOB(PF 3/4) |
| 8. | 2444Z2403D1 | [1] | HOSE | KOB(L=1220MM) |
| 9. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 10. | 2444R3074 | [1] | TEE | KOB(PF 3/4) |
| 11. | 2444R1170D6 | [1] | HOSE | KOB(L=680MM) |
| 13. | HX31E04130DX | [1] | HOSE | KOB(PF 1/4, L=1300MM) |
| 14. | HX21E04040DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=400MM) Superseded by part number: 2420R349D040 |
| 16. | HX31E04050DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=500MM) |
| 17. | 2416P19704 | [1] | BRACKET | KOB |
| 19. | ZS18C06020 | [2] | SCREW,Hex, M6 x 20mm | KOBM06x1.0x20mm |
| 20. | ZS18C08050 | [2] | SCREW,Hex, M8 x 50mm | KOBM08x1.25x50mm |
| 21. | 2420T6786 | [2] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12025 |
| 22. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 23. | 2444T2544 | [1] | ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 24. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 25. | HX21E04035DX | [2] | FLEXIBLE HOSE | KOB(PF 1/4, L=350MM) Superseded by part number: 2420R349D035 |
| 26. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 27. | HX21E04180DX | [3] | HOSE | KOB(PF 1/4, L=1800MM) Superseded by part number: 2420R349D180 |
| 28. | HX21E04035DX | [1] | FLEXIBLE HOSE | KOB(PF 1/4, L=350MM) Superseded by part number: 2420R349D035 |
| 29. | 2444T2592 | [2] | TEE | KOB3/8" PF - 1/4" PF (No O-Ring supplied) |
| 30. | 2444Z2336 | [3] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 31. | 2444Z2544 | [2] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
| 32. | 2444T2524 | [1] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 33. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 34. | ZH32X04000 | [6] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
