| A1. | YN43H01641P1 | [1] | TUBE,42.7 mm OD x 1148.5, 88.6 mm Length | KOB |
| A2. | YN43H01642P1 | [1] | TUBE,34.0 mm OD x 1148.5, 88.6 mm Length | KOB |
| A3. | YN43H01211D7 | [1] | HOSE,25.4mm ID x 1700mm L | KOB |
| A4. | LC43H01011DF | [1] | HYDRAULIC HOSE,31.8mm ID x 1650mm L | KOB1800mm Long (70-7/8 in) |
| A5. | 24100P3133F1 | [2] | VALVE | KOBIncls. Refs. A5-1 - A5-10 |
| A5-1. | 2436P317 | [1] | Body, Valve | |
| A5-2. | 2436T311 | [1] | VALVE | KOB |
| A5-3. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| A5-4. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| A5-5. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| A5-6. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| A5-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| A5-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| A5-9. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| A5-10. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| A6. | YN43H01005P1 | [2] | HYD CONNECTOR | KOB1-7/16"-12UNS x 1-1/4" PF x 87.5mm Long (Incls. O-Ring ZD12P03800) |
| . . | ZD12P03800 | [1] | O-RING | KOB(Part of YN43H01005P1), ID 37.70 ± 0.37 x OD 44.7mm, Not Shown |
| A7. | ZD12A02100 | [2] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| A8. | ZE13X16000 | [4] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| A9. | ZE13X20001 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) Superseded by part number: ZE13X20000 |
| A10. | YN42H02361P1 | [4] | CLAMP,52mm ID, J Type | KOBØ26x65x52mm |
| A11. | YN42H02363P1 | [4] | CLAMP,46mm ID, J Type | KOBØ23x65x52mm |
| A12. | YN43H01524P1 | [2] | BUSHING,34mm ID x 53mm OD x 83mm L | KOBID 34 x OD 43 x 83mm Long |
| A13. | YN42H02321P1 | [2] | BUSHING,42.7mm ID x 62mm OD x 83mm L | SMID 42.7 x OD 62 x 83mm Long |
| A14. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| A16. | ZM73C12030 | [8] | BOLT,M12x30mm - Course Thread | KOBM12x1.75x30mm (Incls. Washer) |
| A17. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| A18. | ZS28C14050 | [8] | CAPSCREW,Hex Socket Head, M14 x 50mm | KOBSCREW M14x2.0x50mm |
| A19. | YN43H01151P1 | [8] | WASHER | KOBID 8.5 x OD 23 x Th 4.5mm |
| A21. | ZS28C12050 | [8] | CAPSCREW,Hex Socket Head, M12 x 50mm | KOBSCREW M12x1.75x50mm |
| A22. | ZW26K12000 | [8] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| A23. | ZW26K14000 | [8] | LOCK WASHER | KOBID 14 x OD 21.8 x Th 3.5mm |
| B1. | YN43H01663P1 | [2] | BRACKET | KOB |
| B2. | ZS18C16040 | [4] | SCREW,Hex, M16 x 40mm | KOBM16x2.0x40mm |
| B3. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
