纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (5.027-01[00]) - HYDRAULIC LINES, CYLINDER (BOOM) (YN42H00412F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
507 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YN42H02812P1 | [1] | TUBE,21.7 mm OD x 1210.5, 224.1 mm Length | KOBTube |
| A2. | ZX20H10072 | [2] | HOSE | KOB720mm Long (28-11/32 in) |
| A3. | ZX20H16078 | [2] | HOSE | KOB780mm Long (30-45/64 in) |
| A4. | YN42H02615P1 | [1] | BAND | KOB |
| A5. | YN42H02813P1 | [1] | BAND | KOBBand |
| A6. | YX42H01074P2 | [2] | BAND | KOB |
| A7. | YY42H01184P1 | [2] | CLAMP | KOB |
| A8. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB1/4" PT - 1/4" PF x 37mm Long |
| A9. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A10. | ZD12P02600 | [1] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| A11. | ZD12A01600 | [1] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| A12. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| A13. | ZS18C12065 | [2] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| A14. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm |
| A15. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A16. | ZW16H12000 | [2] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| B1. | YN42H02342P1 | [1] | TUBE,21.7 mm OD x 1211, 244 mm Length | KOB1211mm Long (47-43/64 in) |
| C1. | YN42H02616P1 | [1] | TUBE,34.0 mm OD x 443, 208.5 mm Length | KOBTube |
| C2. | YN42H02816P1 | [1] | TUBE,34.0 mm OD x 430, 208.5 mm Length | KOBTube |
| C3. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| C4. | ZD12A02100 | [2] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| C5. | ZS28C12040 | [8] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
