神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (06-002) - SWING FLASHER LAMP ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
465 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN80S00015F3 | [1] | LAMP | KOB |
| . . | YN80S00015F4 | [1] | LAMP | KOB |
| 1. | YN80S00015S001 | [4] | BULB | KOB Superseded by part number: 2456U85S4 |
| 4. | YN80S00015S004 | [1] | LENS | KOB |
| 5. | YN80S00015S005 | [1] | LENS | KOB |
| 6. | YN80S00015S006 | [1] | LENS | KOB |
| 7. | YN80S00015S007 | [1] | LENS | KOB |
| 8. | YN80S00015S008 | [1] | CABLE | KOB |
| 9. | YN80S00015S009 | [1] | GASKET | KOBGASKET |
| 10. | YN80S00015S010 | [2] | SCREW | KOBM05x25mm |
| 11. | YN80S00015S011 | [4] | SCREW | KOBM06x40mm |
| 12. | YN80S00015S012 | [1] | BODY | KOBBODY ASSY, RH(FOR F3 ONLY ) |
| 13. | YN80S00015S013 | [1] | BODY | KOBBODY ASSY, LH(FOR F4 ONLY) |
