神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (06-005) - CYLINDER ASSY, DOZER LIFT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
454 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U2040 | [1] | LIFT CYLINDER | KOBLIFE, CYLINDER Superseded by part number: AW317-002-557 |
| 1. | 2438U2040S001 | [1] | TUBE, CYLINDER | |
| 2. | 2444Z4657 | [4] | PLUG | |
| 3. | 2438U2040S003 | [1] | PLATE | |
| 4. | 2445Z1615 | [2] | SEAL | |
| 5. | 2405P797 | [1] | BUSHING | BUSHING |
| 6. | 2439P474 | [1] | ROD | |
| 7. | ZG91S02000 | [3] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 8. | 2439P476 | [1] | PISTON | |
| 9. | 2438U2040S009 | [1] | HEAD, CYLINDER | |
| 10. | 2420T9287 | [4] | BOLT,41/2" | |
| 11. | 2420T9290 | [4] | WASHER, LOCK,5/8" | |
| 12. | 2420T9282 | [1] | NUT | |
| 13. | 2445Z1616S001 | [1] | RING, WEAR | |
| 14. | 2445Z1616S002 | [1] | SEAL, PISTON | |
| 15. | 2445Z1616S003 | [1] | O-RING | |
| 16. | 2445Z1616S004 | [1] | RING, WIPER | |
| 17. | 2445Z1616S005 | [1] | SEAL, ROD | |
| 18. | 2445Z1616S006 | [1] | SEAL, ROD | |
| 19. | 2445Z1616S007 | [1] | O-RING | |
| 20. | 2445Z1616S008 | [1] | RING, BACK-UP | |
| 21. | 2438U2040S021 | [1] | RING, HEAD | |
| 22. | 2445Z1614 | [4] | SEAL | |
| 23. | 2438U2040S023 | [1] | TUBE | |
| 24. | 2438U2040S024 | [1] | BAR | |
| 25. | 2438U2040S025 | [1] | PLATE | |
| . . | 2445Z1616 | [1] | SEAL | KOBSEAL KIT,INCL. REF13,14,15,16,17,18,19,20 Superseded by part number: AW558-021-025 |
