神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (06-010) - VALVE ASSY, PILOT (AUX ATT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
230 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC30V00004F1 | [1] | PILOT VALVE | KOB |
| . . | LC30V00004F2 | [1] | PILOT VALVE | KOB |
| 1. | 2436U1142S13 | [2] | SHIM | KOB |
| 2. | 2436U1487S7 | [2] | SHIM | KOB |
| 3. | 2436U2755S4 | [1] | SEAT | KOB |
| 4. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 5. | 2436U1354S5 | [2] | SLEEVE | KOB |
| 6. | 2436U1354S6 | [1] | COVER | KOB |
| 7. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 9. | YR30V00004S012 | [2] | SPRING | KOB |
| 10. | YR30V00013S009 | [2] | SPRING | KOB |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 12. | 2436U1354S25 | [2] | SHIM | KOB |
| 13. | YR30V00013S012 | [2] | SHIM | KOB |
| 14. | YN30V00022S015 | [1] | CAM | KOB |
| 15. | YN30V00022S016 | [1] | BOOT | KOB |
| 16. | YN30V00022S017 | [1] | PIN | KOB |
| 18. | 2436U2412S26 | [1] | PLUG | KOB1/4"PF |
| 19. | ZS23C12020 | [1] | CAPSCREW,Hex Socket Head, M12 x 20mm | KOBSCREW M12x1.75x20mm |
| 20. | 2436U1354S15 | [2] | BOLT | KOB |
| 21. | ZS83C08008 | [2] | SCREW | KOBSet -- M08x1.25x08mm |
| 22. | 2436U1354S16 | [2] | WASHER | KOB |
| 23. | 2436U1487S35 | [2] | RIVET | KOB |
| 24. | 2436U1354S19 | [2] | PIN | KOB |
| 25. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 26. | NSS | [3] | NOT SOLD SEPARAT | CON |
| 27. | ZD11P01000 | [2] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 28. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 29. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 30. | NSS | [1] | NOT SOLD SEPARAT | CON |
| . . | 2436U1354S26 | [2] | PISTON | KOB |
