纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (03-020[00]) - CYLINDER ASSY, ARM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
965 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN01V00175F1 | [1] | CYLINDER,Double Acting, 95mm Rod, 1558mm Stroke | KOBASSY,ARM |
| . . | YN01V00175F1R | [1] | REMAN-HYD CYLINDER | KOBSK210-8 TIER 3 ROPS (NA) ASN YQ12U4800 |
| . . | YN01V00175F1C | [1] | CORE-HYD CYLINDER | KOBReturn Number |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTUBE,CYLINDER |
| 3. | YN01V00105S003 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U1018S4 | [1] | BUSHING | KOB |
| 5. | 2438U776S5 | [1] | SNAP RING | KOB |
| 6. | YN01V00175S006 | [1] | RING | KOBBUFFER |
| 7. | YN01V00175S007 | [1] | RING | KOBU |
| 8. | YN01V00105S008 | [1] | BACK-UP RING | KOB |
| 9. | 2438U776S9 | [1] | RING | KOB |
| 10. | ZD12G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOBID 129.40 ± 1.05 x OD 135mm |
| 11. | LQ01V00001S011 | [1] | RING | KOB |
| 12. | ZS23C18080 | [12] | CAPSCREW,Hex Socket Head, M18 x 80mm | KOBSCREW M18x2.50x80mm |
| 13. | YN01V00175S013 | [1] | BEARING | KOBBEARING,CUSHION |
| 14. | YN01V00175S014 | [1] | SEAL | KOBSEAL,CUSHION |
| 15. | YN01V00175S015 | [1] | PISTON | KOBPISTON |
| 16. | LQ01V00001S016 | [1] | RING | KOB |
| 17. | LQ01V00001S017 | [2] | BACK-UP RING | KOB |
| 18. | YN01V00175S018 | [2] | RING | KOBSLIDE |
| 19. | LQ01V00001S019 | [2] | RING | KOB |
| 20. | 2438U953S21 | [1] | SET SCREW | KOB |
| 21. | 2436R624S6 | [1] | BALL | KOB |
| 22. | YN01V00175S022 | [1] | BEARING | KOBBEARING,CUSHION |
| 23. | LQ01V00007S025 | [1] | SEAL | KOB |
| 24. | 2438U1104S25 | [2] | STOP | KOB |
| 25. | 2438U1104S26 | [1] | RING | KOB |
| 26. | YN01V01108P1 | [4] | BUSHING,85mm ID x 95mm OD x 54.5mm L | SMBUSHING |
| 27. | 2438U1102S26 | [4] | SEAL | KOB |
| K. | YN01V00175R100 | [1] | SEAL | SMREPAIR ROD SIDE CONSISTS OF ITEM 6X1, 7X1, 8X1, 9X1, 10X1, 11X1 |
| K. | YN01V00175R200 | [1] | SEAL | SMREPAIR PISTON SIDE CONSISTS OF ITEM 14X1, 16X1, 17X2, 18X2, 19X2, 23X1 |
| K. | YN01V00175R300 | [1] | SEAL | SMREPAIR ALL(ROD + PISTON) CONSISTS OF ITEM 6X1, 7X1, 8X1, 9X1, 10X1, 11X1, 14X1, 16X1, 17X2, 18X2, 19X2, 23X1 |
| K. | YN01V00175R400 | [1] | SEAL | SMREPAIR CONSISTS OF ITEM 1X1, 26X2, 27X2 |
| K. | YN01V00175R500 | [1] | REPAIR KIT | SMREPAIR CONSISTS OF ITEM 2X1, 26X2, 27X2 |
