神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (06-025) - MOTOR ASSY (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
618 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN15V00002F4 | [1] | HYDRAULIC MOTOR | KOB Superseded by part number: YN15V00025F4 |
| 11. | YN15V00002S011 | [1] | ROLLER BEARING | KOB |
| 12. | YN15V00002S012 | [2] | PLUG | KOB |
| 13. | YN15V00002S013 | [1] | GASKET | KOB |
| 14. | YN15V00002S014 | [1] | PISTON | KOB |
| 54. | YN20V00004F1 | [1] | VALVE | KOB |
| 20. | YN22V00014F1 | [2] | VALVE | KOB |
| 20-1. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 101. | YN15V00002S101 | [1] | SHAFT | KOB |
| 111. | YN15V00002S111 | [1] | BLOCK | KOB |
| 113. | YN15V00002S113 | [1] | BUSHING | KOB |
| 114. | YN15V00002S114 | [1] | SPRING | KOB |
| 116. | YN15V00002S116 | [12] | PUSH ROD | KOB |
| 117. | YN15V00002S117 | [1] | SPACER | KOB |
| 118. | YN15V00002S118 | [2] | SPACER | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | YN15V00002S123 | [1] | PLATE | KOB |
| 124. | YN15V00002S124 | [1] | PLATE | KOB |
| 131. | YN15V00002S131 | [1] | PLATE | KOB |
| 301. | YN15V00002S301 | [1] | BODY | KOB |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCASE, VALVE |
| 305. | YN15V00002S305 | [1] | BODY | KOB |
| 351. | YN15V00002S351 | [2] | HYDRAULIC VALVE | KOB Superseded by part number: YN15V00025S351 |
| 355. | YN15V00002S355 | [2] | SPRING | KOB |
| 390. | 2437U407S981 | [1] | LABEL | KOBNAMEPLATE |
| 391. | 2437U407S983 | [2] | RIVET | KOB |
| 401. | ZS23C20045 | [4] | CAP,Hex Socket Head, M20 x 45mm | KOBScrew -- M20x2.5x45mm |
| 437. | ZR26X06000 | [1] | RING | KOBRetaining -- ID 60 x OD 64.2 x Th 2.0mm |
| 438. | ZR26X05200 | [1] | RING | KOBRETAINING |
| 444. | YN15V00002S444 | [1] | ROLLER BEARING | KOB |
| 451. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
| 464. | 2441U667S466 | [1] | PLUG | KOB1/4" PF |
| 472. | 2441U564S735 | [1] | O-RING,3.5mm Thk x 173mm ID, 75 Duro | KOB Superseded by part number: YN15V00025S489 |
| 485. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 488. | ZD12P02800 | [2] | O-RING | KOBID 27.70 ± 0.27 x OD 34mm |
| 706. | 2441U736S706 | [1] | O-RING | KOB |
| 707. | 2415U188S707 | [1] | O-RING | KOB |
| 715. | YN15V00002S712 | [24] | SPRING | KOB Superseded by part number: YN15V00025S712 |
| 742. | YN15V00002S742 | [3] | CLUTCH PLATE | KOB |
| 743. | YN15V00002S743 | [4] | STEP PLATE | KOB |
| 980. | LQ15V00001S982 | [1] | PLUG | KOB |
| 981. | LQ15V00001S983 | [3] | PLUG | KOB |
| 984. | YN15V00002S984 | [1] | PLUG | KOB |
| 992. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 994. | ZE82T12000 | [1] | PLUG | KOB3/4" PT |
| . . | YN15V00002R100 | [1] | PISTON | KOB Superseded by part number: YN15V00012R100 |
| . . | YN15V00002R200 | [1] | REPAIR KIT | KOB |
| . . | YN15V00002R300 | [1] | REPAIR KIT | KOB |
